Description
For audiophiles who demand uncompromising wireless sound without sacrificing portability, the FiiO BTR17 delivers flagship-level performance in a pocketable form factor. Whether you're commuting with LDAC-enabled headphones or setting up a desktop rig with the patented D.Mode, this Bluetooth DAC and amplifier adapts to every listening scenario. The dual ESS ES9069Q DACs paired with the THX AAA 78+ amplifier deliver rich, detailed sound with exceptional clarity across both 3.5mm and 4.4mm balanced outputs. Qualcomm's QCC5181 chipset with Bluetooth 5.4 ensures lossless aptX Adaptive and LDAC streaming, while the 10-band PEQ lets you tailor the sound to your preferred headphones. The physical volume knob, three-position mode switch, and 1.3-inch color display keep controls intuitive on the go. With up to 650mW of balanced output power in desktop mode, the BTR17 handles everything from sensitive IEMs to demanding full-size headphones with ease.
Demo unit; may show light signs of handling. Contact us for photos and details.
Specifications
| Bluetooth chip | Qualcomm QCC5181, Bluetooth 5.4 |
| DAC | ESS ES9069Q × 2 (HyperStream IV, 32-bit) |
| USB DAC controller | XMOS XU316 (16-core) |
| Amplifier | THX AAA 78+ (4-channel balanced, ×8 op-amps) |
| Bluetooth codecs | AAC, SBC, aptX, aptX Adaptive, aptX Lossless, aptX HD, LDAC |
| USB DAC support | PCM up to 768kHz/32bit, DSD up to DSD512 (Native), DOP256 |
| Display | 1.3-inch color IPS |
| Volume control | Physical volume knob |
| Headphone outputs | 3.5mm single-ended, 4.4mm balanced |
| USB ports | Type-C (data/power), Type-C POWER IN (dedicated power) |
| Output (4.4mm balanced, desktop mode, 32Ω) | ≥650mW + 650mW |
| Output (3.5mm, desktop mode, 32Ω) | ≥280mW + 280mW |
| Output (4.4mm balanced, portable mode, 32Ω) | ≥300mW + 300mW |
| SNR (balanced) | ≥126dB (A-weighted) |
| THD+N (balanced) | <0.00035% (1kHz/-10dB@32Ω) |
| Battery life (Bluetooth, balanced) | ≥8h |
| Battery life (phone mode, single-ended) | ≥10h |
| Charging time | ≤2h |
| Dimensions | Approx. 16.3 × 41.2 × 86.6mm |
| Weight | Approx. 73.4g |
| Color options | Black, Blue |
| Modes | PC, BT (Bluetooth), PHONE (phone dongle) |
| Desktop mode | Supported (dedicated switch + POWER IN port) |
| PEQ | 10-band high-precision lossless PEQ |
| Firmware | Bluetooth OTA upgrade, USB firmware upgrade |
| Microphone | Built-in omnidirectional mic for Bluetooth voice calls |
| In-vehicle mode | Automatically turn on/off with vehicle USB |
| Deep standby | Auto power save in 3 minutes (timer adjustable in app) |
